Whirlpool KSCS23FTWH01 Parts List

Popular Searches: (Click to search)    assembly  black  box  connector  defrost  dispenser  door  filter  ice  icemaker  inverter  metal  motor  paint  pressurized  spray  thermistor  touch  water  white


Select a Diagram

01 - Cabinet Parts

02 - Refrigerator Liner Parts

03 - Refrigerator Shelf Parts

04 - Freezer Liner Parts

05 - Motor And Ice Container Parts

06 - Refrigerator Door Parts

07 - Freezer Door Parts

08 - Dispenser Front Parts

09 - Air Flow Parts

10 - Control Parts

11 - Unit Parts

12 - Icemaker Parts

13 - Optional Parts (not Included)

Select Diagram ... 01 - Cabinet Parts 02 - Refrigerator Liner Parts 03 - Refrigerator Shelf Parts 04 - Freezer Liner Parts 05 - Motor And Ice Container Parts 06 - Refrigerator Door Parts 07 - Freezer Door Parts 08 - Dispenser Front Parts 09 - Air Flow Parts 10 - Control Parts 11 - Unit Parts 12 - Icemaker Parts 13 - Optional Parts (not Included)

07 - Freezer Door Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	L2326211SAP	Freezer Door (includes No.8 And Dispenser Front Parts) (monochromatic Stainless)	$1,226.60 Special Order
	L2326211SB	Freezer Door (includes No.8 And Dispenser Front Parts) (stainless Steel)	$640.70 Special Order
	L2326211W	Freezer Door (includes No.8 And Dispenser Front Parts) (white)	$580.20 Special Order
	L2326211B	Freezer Door (includes No.8 And Dispenser Front Parts) (black)	$615.00 Special Order
	L2326211T	Freezer Door (includes No.8 And Dispenser Front Parts) (biscuit)	$615.00 Special Order
2	WP2319727W	Handle (white)	$138.00 Special Order
	WP2319727B	Handle (black)	$152.30 Special Order
	2319727T	Handle (biscuit)	$91.10 Special Order
	WP2319727S	Handle (stainless Steel)   (Replaces: 2319727S)	$113.60 Special Order
3	WPW10170540	Stud, Handle	$6.40  In-Stock Retail: $6.15
4	WP488163	Screw	$4.50  In-Stock Retail: $4.33
5	WP3400012	Screw	$4.50 Special Order
6	WPW10010150	Set Screw (black)	$4.50 Special Order
	W11366418	Set Screw (chrome)	$8.20  In-Stock Retail: $7.99
7	2223559	Shelf Bin (3)   (Replaces: 2304925K)	$21.70 Special Order
8	W10136742	Door Gasket, Magnetic (apollo Grey)	$169.70 Special Order
	2306997	Door Gasket, Magnetic (black)	$147.00 Special Order
	2306993	Door Gasket, Magnetic (mist Beige)	$146.40 Special Order
9	2304895	Safety Barrier	$51.60 Special Order
10	2301049	Thimble, Top	$52.60 Special Order
11	2307050	Door Closer, Upper Cam	$27.60 Special Order
12	WP489483	Screw	$6.30 Special Order
13	2306940B	Bracket, Door Stop (black)	$22.40 Special Order
	2306940	Bracket, Door Stop (chrome)	$56.40 Special Order
NI	2310224	Wire Harness, Freezer Door	$80.10 Special Order
	2317707	Tube, Door	$35.40 Special Order
