06 - Refrigerator Door   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	1116575	Panel, Refrigerator Door (also Order Item 27)	$133.30 Special Order
3	W10833053	Plate, Tap (4)   (Replaces: 943185)	$9.30 Special Order
4	WP2183805	Bracket, Door Stop (Replaces: 944036)	$6.60  In-Stock Retail: $6.35
5	WP488921	Screw, 8 X 1/2	$4.50 Special Order
6	WP8281206	Screw, 8-15 X 1/2 (Replaces: 489028)	$4.50 Special Order
7	WP2212648	Hole Plug	$4.50 Special Order
8	2188447A	Door Gasket, Magnetic (Replaces: 1125889)	$128.50  In-Stock Retail: $125.31
9	WP489069	Screw, 7 X 1/2	$4.50 Special Order
10	1125879	Retainer, Insert	$34.50 Special Order
11	1125788	Handle End Cap	$15.30 Special Order
12	2161508	Handle Assembly	$95.90 Special Order
14	2151813	Shim	$12.50 Special Order
15	WP939101	Screw Anchor (2)	$4.50 Special Order
16	WP488920	Screw, 8 X 5/8	$4.50  In-Stock Retail: $4.33
17	WP488729	Screw, 8 X 1/2	$4.50  In-Stock Retail: $4.33
18	1107651	Spacer, Handle	$4.40 Special Order
19	2157384	Interior Door Panel	$188.30 Special Order
20	2161511	Insert, Handle	Call for Availability
21	1125857	Trim, Door Shelf	Call for Availability
22	1126234	Compartment Door, Utility	Call for Availability
23	1126233	Compartment Door, Butter	Call for Availability
24	WP2189000	Hole Plug, Handle   (Replaces: 1122653)	$4.50 Special Order
25	WP488729	Corner Screw	$4.50  In-Stock Retail: $4.33
26	2157385	Door Dike, Center	Call for Availability
27	876029	Foam Insulation (required When Replacing Exterior Door Panel)	$226.70 Special Order
28	1118007	Door Dike, Side (2)	Call for Availability
30	1126013	Trim, Door	Call for Availability
31	1115136	Retainer, Gasket Side (2)	$16.70 Special Order
32	1115137	Retainer, Gasket Top & Bottom	Call for Availability
33	WP1118001	Hinge Pin, Center	$4.50 Special Order
35	1125862	Shelf Bin (2)	Call for Availability
36	1125863	Shelf Bin (2)	Call for Availability
37	1106959	Trim, Compartment	$47.80 Special Order
38	1126137	Wine & Egg Rack   (Replaces: 1125913)	$29.40 Special Order
39	2148588	Trim, Comp. Door Door	Call for Availability
