Maytag CE38800AAW Parts List

Popular Searches: (Click to search)    1200w  bake  block  broiler  bulb  door  element  gasket  infinite  insert  kit  long  lrg  oven  pan  sensor  sml  switch  terminal  tip


Select a Diagram

01 - Body

02 - Control Panel/top Assembly

03 - Door/drawer

04 - Door/drawer (series 15)

05 - Oven/base

06 - Supplemental Information

07 - Wiring Information

Select Diagram ... 01 - Body 02 - Control Panel/top Assembly 03 - Door/drawer 04 - Door/drawer (series 15) 05 - Oven/base 06 - Supplemental Information 07 - Wiring Information

03 - Door/drawer   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	74010338	Handle, Door (blk) (Series: 10)	$66.70 Special Order
	7701P539-60	Handle, Door (blk) (Series: 16)	$61.60 Special Order
2	3801F850-51	Bracket, Clock (Series: 10)	$45.40 Special Order
3	74008718	Switch, Rocker (blk) (Series: 10)	Call for Availability
4	WP74004153	Light, Indicator (Series: 10)   (Replaces: 74004153)	$4.50 Special Order
5	WP7730P011-60	Lens, Indicator Light (Series: 10)	$3.30 Special Order
6	WP7403P238-60	Switch, Infinite (sml Element) (Series: 10) (Replaces: 7403P238-60)	$40.00  In-Stock Retail: $56.27
	WP7403P239-60	Switch, Infinite (lrg Element) (Series: 10) (Replaces: 7403P239-60)	$33.50  In-Stock Retail: $49.21
	WP74003122	Switch, Infinite (dual) (Series: 10)   (Replaces: 74003122)	$70.30  In-Stock Retail: $68.56
7	5701M760-60	Clock W/overlay (blk) (Series: 10)	$264.00 Special Order
	W11233072	Screw (8ab1/2-ni) (Series: 10)	$8.20  In-Stock Retail: $7.99
8	WP98008545	Screw (blk) (Series: 10)	$11.00  In-Stock Retail: $10.67
	3807F733-70	Support, Backguard (rt-blk) (Series: 10)	$23.90 Special Order
	74010202	Support, Backguard (lt-blk) (Series: 10)	$4.40 Special Order
9	WP90767	Screw (Series: 10)	$4.50  In-Stock Retail: $4.33
	3604F387-51	Shield, Rear Sight (Series: 10)	$4.40 Special Order
10	4005F804-51	Cover, Rear Wire (upr) (Series: 10)	$32.20 Special Order
	WP90767	Screw (Series: 10)	$4.50  In-Stock Retail: $4.33
11	74010332	Knob (blk) (Series: 10)	$6.00  In-Stock Retail: $5.85
12	5706X523-09	Asy., Main Top (blk) (Series: 10)	$282.80 Special Order
13	WP7101P309-60	Screw (Series: 10)	$4.50 Special Order
14	W11233072	Screw (8ab1/2-ni) (Series: 10)	$8.20  In-Stock Retail: $7.99
15	W10823715	Element (2500w) (Series: 10)   (Replaces: WP74009743 74009743)	$196.40 Special Order
16	W10823711	Element (1200w) (Series: 10) (Replaces: 12002141 74008568)	$196.40  In-Stock Retail: $191.60
17	W11189172	Glide, Main Top (Series: 10)	$10.40 Special Order
18	3604F405-51	Shield, Wire (Series: 10)	$8.10 Special Order
	WP90767	Screw (Series: 10)	$4.50  In-Stock Retail: $4.33
19	W10823709	Element, Dual (Series: 10)	$177.00  In-Stock Retail: $172.60
22	WP74005546	Spacer, Rubber (Series: 10)	$6.10 Special Order
23	WP74004078	Roller, Drawer (Series: 10)   (Replaces: 74004078)	$7.00 Special Order
24	WP74005231	Shaft, Storage Drawer Roller (Series: 10)   (Replaces: 74005231)	Call for Availability
25	WP488130	Nut (Series: 10) (Replaces: 7103P082-60)	$4.40  In-Stock Retail: $4.20
