03 - Burner Box, Gas Valves And Switches   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	8186533	Bracket, Cooktop Mounting	$51.70 Special Order
2	9759354	Pipe, Manifold	$91.20 Special Order
3	WP4456905	Harness, Switch (Replaces: 4456905)	$124.90  In-Stock Retail: $121.83
4	WPW10110491	Module, Spark	$182.40  In-Stock Retail: $177.94
5	WP4456817	Valve, Gas (large) (left Front, Left Rear, Right Rear) (Replaces: 4456817)	$173.80  In-Stock Retail: $169.51
5A	WP4456816	Valve, Gas (small) (right Front) (Replaces: 4456816)	$173.90 Special Order
6	W10392007	Cord, Power	$63.60 Special Order
7	WP7101P434-60	Screw	$4.50 Special Order
8	12002277	Screw	$168.20 Special Order
9	9760045	Seal, Foam	$152.40 Special Order
10	3191318	Tube (right Front & Right Rear)	$67.00 Special Order
11	8286858	Plate, Manifold	$11.50 Special Order
12	3191320	Tube (left Front & Left Rear)	$70.40  In-Stock Retail: $68.60
13	WP90767	Screw	$4.50  In-Stock Retail: $4.33
14	4456780	Box, Burner	$206.70 Special Order
15	W11170853	Regulator, Pressure	$186.90 Special Order
16	WP3400093	Screw   (Replaces: 3400093)	$4.50 Special Order
17	W10203756	Rail, Burner	$6.00 Special Order
18	WP3188425	Seal, Shaft	$51.60 Special Order
