GE CFSP5RKBE SS Parts List

Popular Searches: (Click to search)    asm  cond  crank  cyst  def  door  fan  filt  flap  gasket  inverter  motor  recess  ref  sensor  solenoid  temperature  thermostat  water  with


Select a Diagram

10 - Machine Compartment

1 - Dispenser Door

2 - Clad Components

3 - Doors & Bins

4 - Freezer Section

5 - Freezer Shelves

6 - Ice Maker & Dispenser

7 - Fresh Food Section

8 - Fresh Food Shelves

9 - Case Parts

Select Diagram ... 10 - Machine Compartment 1 - Dispenser Door 2 - Clad Components 3 - Doors & Bins 4 - Freezer Section 5 - Freezer Shelves 6 - Ice Maker & Dispenser 7 - Fresh Food Section 8 - Fresh Food Shelves 9 - Case Parts

1 - Dispenser Door   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
6	WR02X13502	Rivet Clinch	$10.50 Special Order
13	WR12X11044	Handle Asm Commercial	Call for Availability
14	WR02X12028	Fastener Handle Ss	$21.30 Special Order
33	WR78X12822	Service Kit I&w Door	Call for Availability
35	WR14X10237	Gasket French With Flap	$228.30 Special Order
38	WR02X13521	Stop Door Bm	Call for Availability
43	WR02X13520	Cam Ff Closure Lh	Call for Availability
50	WR17X12979	Module Shelf Asm Ff	Call for Availability
61	WR17X12771	Housing Shield Disp	$27.70 Special Order
62	WR17X12983	Funnel Ice Dispenser	Call for Availability
63	WR02X13485	Spring Torsion	Call for Availability
64	NLA ITEM	Trim Asm Cafe	Call for Availability
65	WR17X13013	Paddle Asm	Call for Availability
66	NLA ITEM	Articulation Mullion Asm	Call for Availability
67	WR02X12469	Bumper French Door	$14.50 Special Order
69	WR17X12324	Grille Recess	Call for Availability
88	WR01X10656	Scr 4-10 Pl Pnp 5/16 S5h	$10.50 Special Order
93	WR55X11100	Interface Dispenser Asm	$248.10 Special Order
137	WR23X10783N	Switch   (Replaces: WR23X10224)	$58.50  In-Stock
138	WR02X12257	Scr 4-10 Pl Pnp 3/4 Ss	$13.40 Special Order
139	WR55X10899	Board Asm Disp Lighting	$53.70  In-Stock Retail: $52.36
140	WR23X10657	Harness Recess Disp	Call for Availability
141	WR02X13512	Thimble Door Ff	Call for Availability
142	WR02X13487	Clip Mullion Hinge	Call for Availability
143	WR62X10055	Solenoid Asm	$49.80  In-Stock Retail: $65.19
144	WR02X13488	Spring Water Conduit	$10.90 Special Order
145	WR02X13489	Spring Water Conduit	Call for Availability
146	WR17X12984	Door Ice Box Asm	$260.60 Special Order
147	WR14X10355	Gasket Icebox Door	Call for Availability
148	WR13X10926	Door Icebox Hinge Top	Call for Availability
149	WR13X10927	Door Icebox Hinge Bottom	Call for Availability
150	WR01X10977	Scr 8-18 Hi-lo Flp 1/2 S	Call for Availability
151	WR02X13490	Latch Button	Call for Availability
152	WR02X13491	Latch Trim	Call for Availability
153	WR14X10356	Gasket Retainer	Call for Availability
154	WR14X10357	Port Gasket	Call for Availability
155	WR02X13492	Spring Duct Door	Call for Availability
156	WR49X10261	Door Latch Kit Bf I&w	Call for Availability
238	WR01X10789	Scr 8-18a Fl Hd 5/8 Ss	$10.50 Special Order
368	WR17X10706	Crank Door Recess	$10.50  In-Stock Retail: $10.22
369	WR17X13004	Duct Door Heater Asm	Call for Availability
371	WR2X8818	Retainer Recess Door	$10.50 Special Order
373	WR02X13506	Foam Tape	Call for Availability
910	WR01X10649	Screw 8-10 Pl Pnp 1/2 S	$10.10 Special Order
