Whirlpool KUWS24LSBS02 Parts List

Popular Searches: (Click to search)    bottom  bracket  defrost  drain  drier  heater  hinge  light  pan  switch  thermostat  timer  washer


Select a Diagram

01 - Cabinet Parts

02 - Shelf Parts

03 - Door Parts

04 - Unit Parts

Select Diagram ... 01 - Cabinet Parts 02 - Shelf Parts 03 - Door Parts 04 - Unit Parts

03 - Door Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	4344854	Door Assembly (includes Gasket)	$342.70 Special Order
2	4344813	Nameplate	$41.90 Special Order
3	W10163191	Gasket, Push Plate	$9.50 Special Order
4	4344787	Hinge, Bottom	$120.50 Special Order
5	4344754	Hinge, Top	$45.50 Special Order
6	4344755	Spacer, Top Hinge	$11.70 Special Order
7	4344756	Spacer, Bottom Hinge	$11.70 Special Order
8	4344757	Actuator, Switch	$89.90 Special Order
9	4344758	Door Stop	$10.60 Special Order
10	WPW10238068	Door Gasket	$178.60 Special Order
11	WP9872207S	Handle, Door	$113.60 Special Order
12	4344856	Door Skin, Stainless Steel	$370.60 Special Order
13	4344760	Washer	$8.20 Special Order
14	4344788	Spacer, Door	$95.90 Special Order
15	W10238056	Plate	$22.70 Special Order
16	4344796	Screw	$9.50 Special Order
17	W10243104	Screw, Lower Hinge (quantity 3)	$9.50 Special Order
	4344906	Screw, Lower Hinge (quantity 1)	$7.90 Special Order
18	W10837731	Screw	$4.50  In-Stock Retail: $4.33
19	W10243123	Screw	$9.50 Special Order
20	4344801	Screw	$9.50 Special Order
21	4344808	Screw	$9.50 Special Order
NI	31462A	Cleaner, Stainless Steel (12 Oz.)	$7.20 Special Order
